| 型號Model | ZJ5822A |
| 面線剪線裝置face thread trimmer | 自動剪面線Auto trimmer top-thread |
| 底線剪線裝置bobbin thread trimmer | 短線剪切Short thread cut |
| 用途Application | 男裝、女裝men's and women's cloth |
| 縫制速度Speed | 1000~2700rpm(可以100rpm為單位設定Itcanbe set at 100rpm) |
| 功能Features | 剪線裝置可較短的剪切所有線頭。在縫紉持續過程中可在更短距離內安全把握線尾。減少水洗后二次修剪線頭。The thread cutter can cut all thread endsshorter.In the process of sewing can beheld in a shorter distance. Reducesecondary trimming after washing. |
| 針跡形狀stiich appearance |
|
| 線尾長度End length | 5-6mm |
| 鎖逢長度holing length | 5-30mm |
| 針跡節距stitch length | 0.5~2.0mm |
| 針跡幅寬stitch width | 1.5mm~5.0mm(機械式1.5mm~4.0mm、程序式可加寬1.0mm1.5mm~5.0mm( mechanical1.5mm~4.0mm、 program can increase width1.0mm ) |
| 錐形加固長度cone-shape reinforce length | 0~20mm |
| 壓腳高度foot lifter height | 標準為12mm(可以到16mm為止)standard12mm(maximum achievel6mm ) |
| 啟動方式start mode |
腳踏開關(腳踏板式、2連腳踏板式)或是手動開關 Pedal switch( by pedal, double pedal)or manual |
| 送布方式,cloth feed mode | X、Y、?的3脈沖馬達間歇送布pause feed by 3 pulse motor |
| 機針Needle | DOx558-NY2 #14~#18(風琴) |
| 安全裝置safety device |
內藏暫停功能及當安全電路發生故障時的自動停止裝置 With built-in pause function and auto stop device when error of circuit |
| 上軸馬達axle motor | Ac伺服馬達(4極 550W)AC servo motor (4P 550W) |
| 空氣壓力air pressure |
主調節器:0.5MPa錘子壓力調節器:0.4MPahammer
pressure regulator 0.4MPa main regulator 0.5MPa |
| 空氣消耗量air consumption | 43.2 1/min(8次循環/min)8 times cycle/min |
| 電源Power |
單相100V/200V、三相200V/220V/380V/400V
400VA Single phase100V/200v、3-phase200V/220V380V/400V 400VA |
| 重量Weight |
頭部約120kg、操作盤約0.6kghead120kg、
panel0.6kg控制箱14.2~16.2 kg(根據出口國的不同而不同) control box14.2~16.2 kg |
|
|
|
