| 型號Model | ZJ-M7-S955H-SF-V3 | ZJ-M7-S955H-SF-LK2-V3 |
| 機針Needle | DPX5 7~14# | DPX5 7~14# |
| 轉速Sewing speed |
3200rpm(針距3.5mm以內） 3200rpm(Needle gauge within 3.5mm) |
3200rpm(針距3.5mm以內） 3200rpm(Needle gauge within 3.5mm) |
| 縫紉范圍Sewing area | 1400x955mm | 1400x955mm |
| 針距長度Stitch length |
0.05~12.7mm(0.05mm 單位) 0.05~12.7mm(0.05mm Unit) |
0.05~12.7mm(0.05mm 單位) 0.05~12.7mm(0.05mm Unit) |
| 中壓腳行程Medium pressure foot stroke |
標準3mm Standard 3mm |
標準3mm Standard 3mm |
| 存儲花樣Pattern Storage |
最多999個花樣(單個花樣最大50000針) Maximum 999 patterns(maximum50000 needles for one pattern) |
最多999個花樣(單個花樣最大50000針) Maximum 999 patterns(maximum50000 needles for one pattern) |
| 識別模板Identification of the template |
對模板能自動識別999個花樣 Automatically identify 999 kinds of templates |
對模板能自動識別999個花樣 Automatically identify 999 kinds of templates |
| 文件格式File format |
支持.DXF/.PLT等格式文件 Support format files, such as dxf/.plt etc |
支持.DXF/.PLT等格式文件 Support format files, such as dxf/.plt etc |
| 輸入電壓范圍 Input voltage | 220V+ 44V | 220V+ 44V |
| 輸出功率Output power | 600W | 600W |
