型號 model
|
ZJ-UB-1903D-DK-WB5
|
|
搭載機頭 Carrying nose
|
ZJ1903D-3/04-74
|
|
最高縫制速度 Maximum sewing speed
|
2700sti/min
|
|
紐扣間隔 Button spacing
|
任意設定:全長<655mm Arbitrary setting:totallength ≤ 655mm
|
|
紐扣與縫料邊緣間隔 Button and seam edge spacing
|
9-21mm
|
|
使用紐扣種類Types of buttons used
|
圓形平紐扣標準:四眼;二眼(可選三眼;五眼)
Round flat button standard: four eyes;Two eyes (optional three eyes; five
eyes)
|
|
使用針 Using needles
|
DPX17
|
|
紐扣直徑 Button diameter
|
Φ9~Φ20
|
|
紐扣厚度 Button thickness
|
1.8-4mm
|
|
最大縫料輸送距離 Maximum seam material conveying
distance
|
<650mm
|
|
上端間隔 Upper interval
|
<50mm
|
|
標準紐扣縫制形狀 Standard button sewing shape
|
50個
|
|
紐扣縫制設定范圍 Button sewing setting range
|
2-20個
|
|
電壓 voltage
|
220V
|
|
氣壓、空氣消費量Air pressure,air consumption
|
0.5MPa 1.8 1/min
|
|
機器重量(凈重)Machine weight(net weight)
|
322KG
|
|
機器重量(毛重)Machine weight (gross weight)
|
414KG
|
|
機器尺寸(長X寬X高)Machine size (length xwidth
xheight)
|
2220X1120X1430mm
|
|
包裝尺寸(長X寬X高) Packaging size (length xwidth
xheight)
|
2300X1420X1500mm
|
